METSpc Navy Detachable Links which's specs are defined at drawing 860062. All materials could be traceble and meet MIL-DTL-18295 and MIL-DTL-2710. Materials protective finish standard colour is black. All Detachable Links have been applied to proof load. NDetachable Links with Hairpin, and without hairpin options are available. For commercial Detachable Links please contact us.
| 860062 SERIES | |||
| Link Size (inc) | Federal Stock No (NSN) | Proof Load (lb) | Breaking Load (lb) |
| 3/4 | 4010-00-106-9474 | 67,500 | 91,100 |
| 7/8 | 4010-00-106-9473 | 88,200 | 119,000 |
| 1 | 4010-00-106-9472 | 116,100 | 156,700 |
| 1-1/8 | 4010-00-106-9471 | 145,000 | 195,000 |
| 1-1/4 | 4010-00-106-9470 | 178,200 | 240,600 |
| 1-3/8 | 4010-00-106-9469 | 211,500 | 285,500 |
| 1-1/2 | 4010-00-106-9468 | 252,000 | 340,200 |
| 1-5/8 | 4010-00-106-9467 | 292,500 | 395,000 |
| 1-3/4 | 4010-00-106-9466 | 352,000 | 476,000 |
| 1-7/8 | 4010-00-106-9459 | 285,000 | 432,000 |
| 2 | 4010-00-106-9458 | 322,000 | 488,000 |
| 2-1/8 | 4010-00-106-9457 | 362,000 | 548,000 |
| 2-1/4 | 4010-00-106-9456 | 403,000 | 610,000 |
| 2-3/8 | 4010-00-106-9455 | 447,000 | 675,000 |
| 2-1/2 | 4010-00-106-9454 | 492,000 | 744,000 |
| 2-5/8 | 4010-00-106-9453 | 540,000 | 813,000 |
| 2-3/4 | 4010-00-106-9452 | 590,000 | 888,000 |
| 2-3/4 HD | 4010-00-106-9438 | 649,000 | 981,000 |
| 2-7/8 | 4010-00-106-9450 | 640,000 | 965,000 |
| 3 | 4010-00-106-9442 | 693,000 | 1,045,000 |
| 3 HD | 4010-00-106-9442 | 762,000 | 1,150,000 |
| 3-1/8 | 4010-00-106-9448 | 748,000 | 1,128,000 |
| 3-1/4 | 4010-00-106-9447 | 805,000 | 1,250,000 |
| 3-3/8 | 4010-00-106-9446 | 862,000 | 1,304,000 |
| 3-1/2 | 4010-00-106-9445 | 922,000 | 1,383,100 |
| 3-1/2 HD | 4010-00-106-9441 | 1,080,000 | 1,700,000 |
| 3-3/4 | 4010-00-106-9444 | 1,045,900 | 1,575,000 |
| 4-3/4 | 4010-00-106-9460 | 1,700,000 | 2,550,000 |
